SECTION 4 - ENGINE AND ATTACHING PARTS
31200727 G10-43A,G9-43A,G6-42A 103
FIGURE 4-5. FUEL TANK AND LINES IF EQUIPPED FOR ULS
ITEM PART NUMBER QTY DESCRIPTION REV
1001130780 Ref FUEL TANK ASSY, (if equipped for ULS), (not available to order,
see items 1 thru 11 for service) C
1 1671313 1 FUEL SENDER COVER
2 1001134413 1 FUEL TANK
3 4923452 1 FUEL SENDER HARNESS
5 1001148837 1 FUEL LEVEL SENDER
6 1001130776 2 HOSE BARB ADAPTER
7 0100093 AR LOCTITE 30512
8 1001148847 3 ADAPTER
9 4811600 3 WASHER, 5mm
10 0731003 2 HEX HD MACHINE SCREW, 10-32X3/8
11 1001149344 3 SPECIAL NUT, 8-32
109 0761010 1 HEX HD CAPSCREW, M10X20, GR8.8
111 1321716 1 DOUBLE P-CLAMP
122 4832000 1 LOCKWASHER, 10mm
129 1001102931 2 BANJO BOLT, M14
130 1001102933 4 COPPER RING SEAL
132 1001113511 2 BANJO ADAPTER, M14X3/8
149 1001136975 8 FUEL HOSE CLAMP
152 1001144802 1 HOSE CLAMP
153 1001080998 1 FUEL FILTER DRAIN HOSE
154 1001141400 323 in FUEL HOSE
227 Ref FUEL RADIATOR, (See RADIATOR AND COOLING
INSTALLATION for Breakdown)
301 Ref PRIMARY FUEL FILTER ASSY, (See ENGINE for Breakdown)
401 1001093641 1 FUEL CAP, NON-LOCKING
401 1001102657 1 FUEL CAP, LOCKABLE, (includes items 402 thru 404) A
402 0100093 AR LOCTITE 30512
403 1001001422 1 FILLER NECK TANK ADAPTER
404 1001080707 1 LOCKING FUEL CAP
510 0641608 3 HEX HD CAPSCREW, 3/8-16X1
519 4711600 3 WASHER, 3/8
521 4761600 3 LOCKWASHER, 3/8
533 1001150364 3 FUEL TANK HOLD DOWN
