SECTION 8 - HYDRAULIC CIRCUITS
31200727
G10-43A,G9-43A,G6-42A
305
FIGURE 8-18. FRAME LEVEL CIRCUIT
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
0641408
3
HEX HD CAPSCREW, 1/4-20X1, GR5, (G6-42A)
1
0641408
4
HEX HD CAPSCREW, 1/4-20X1, GR5, (G9-43A & G10-43A)
3
0641414
3
HEX HD CAPSCREW, 1/4-20X1-3/4, GR5
13
2110606
2
ADAPTER, CONNECTOR, (includes o-ring)
24
4751400
3
WASHER, 1/4, (G6-42A)
24
4751400
4
WASHER, 1/4, (G9-43A & G10-43A)
25
4031709
2
HEX SOC HD SCR, M6 X 25 LG, (G9-43A, if equipped with tilt on
joystick), (G10-43A)
26
4761400
3
LOCKWASHER, 1/4
39
77133270
3
CLAMP SET, (G6-42A)
39
77133270
4
CLAMP SET, (G9-43A & G10-43A)
46
91473188
1
FRAME LEVEL CYLINDER VALVE
52
1001101615
1
HYDRAULIC PIPE, (G6-42A)
52
1001105339
1
HYDRAULIC PIPE, (G9-43A & G10-43A)
53
1001101616
1
HYDRAULIC PIPE, (G6-42A)
53
1001105338
1
HYDRAULIC PIPE, (G9-43A & G10-43A)
75
1001096957
2
HOSE ASSEMBLY, (G6-42A)
75
1001118560
2
HOSE ASSEMBLY, (G9-43A & G10-43A)
80
91123062
3
CABLE ADAPTER BONNET, (G6-42A)
80
91513124
3
CABLE ADAPTER BONNET, (G9-43A)
80
91513124
1
CABLE ADAPTER BONNET, (G9-43A, if equipped with tilt on
joystick), (G10-43A)
103
2110608
1
ADAPTER, CONNECTOR, (includes o-ring), (G6-42A)
103
2110612
2
ADAPTER, CONNECTOR, (includes o-ring), (G9-43A & G10-43A)
108
2130608
1
ADAPTER, 90, (includes o-ring)
111
2172106
1
ADAPTER, 90, (includes o-ring)
113
Ref
MAIN CONTROL VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
214
Ref
FRAME LEVEL CYLINDER, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
302
Ref
FRAME LEVEL CONTROL, (See CONTROLS SECTION for
Breakdown)
402
Ref
AUXILIARY HYDRAULIC CONTROL, (See CONTROLS SECTION
for Breakdown)
502
Ref
TILT AND FRAME LEVEL CONTROL, (See CONTROLS SECTION
for Breakdown)
