SECTION 5 - DRIVE TRAIN
31200727
G10-43A,G9-43A,G6-42A
183
FIGURE 5-26. ZF TRANSMISSION - 1ST SHAFT GROUP
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
7026761
2
PISTON RING
2
1319608
1
ROLLER BEARING
3
1319591
1
COUPLING
4
8036575
1
PISTON
5
1319595
5
CUP SPRING
6
1319596
1
SHIM
7
10731845
2
RETAINING RING
8
7026758
12
FRICTION DISC
9
7026759
12
STATIC DISC
10
7026760
1
END SHIM
11
1319600
AR
SNAP RING, 4.0
11
7029850
AR
SNAP RING, 3.75
11
1319601
AR
SNAP RING, 3.5
11
7029849
AR
SNAP RING, 3.25
11
1319602
AR
SNAP RING, 3.0
11
7029852
AR
SNAP RING, 2.75
11
1319603
AR
SNAP RING, 2.5
11
7029851
AR
SNAP RING, 2.25
11
1319604
AR
SNAP RING, 2.0
12
1319606
2
ROLLER CAGE
13
1319607
1
DISC CARRIER
14
7029532
1
OUTER RING
15
7029533
1
INNER RING
