SECTION 5 - DRIVE TRAIN

31200727

G10-43A,G9-43A,G6-42A

201

FIGURE 5-35. FENDER INSTALLATION

ITEM

PART NUMBER

QTY

DESCRIPTION

REV

1001142564

1

FENDER INSTALLATION, (includes items 1 thru 11)

C

1

1001142561

4

FENDER BRACKET

3

83191010

16

LOCKWASHER

4

91514118

16

FENDER STUD

5

91513266

16

HEX NUT, M12X1-1/4

6

4811902

32

WASHER, 8mm

7

0760812

16

HEX HD CAPSCREW, M8X25, GR8.8

11

1001095650

AR

LOCTITE 243

12

1001154055

4

FENDER DUNLOFLEX

101

Ref

WHEEL ASSY, (See WHEEL ASSEMBLY for Breakdown)
