SECTION 9 - HYDRAULIC COMPONENTS
31200727 G10-43A,G9-43A,G6-42A 341
FIGURE 9-16. OUTRIGGER CYLINDER
ITEM PART NUMBER QTY DESCRIPTION REV
1001116439 2 OUTRIGGER CYLINDER, (G10-43A), (includes items 1 thru 20),
(included item quantities are per single cylinder) B
1 70020370 4 BUSHING
2 70023892 1 BARREL
3 70023893 1 PISTON, (loctite and torque to 2350-2600 lb-ft/3186-3525 Nm)
4 70023894 1 HEAD GLAND, (torque to 300-400 lb-ft/407-542 Nm)
5 70023895 1 ROD
6 8036629 1 SET SCREW, 3/8-16X3/4, (torque to 16-18 lb-ft/22-24 Nm)
7 70023896 1 TAPPING SCREW
8 70023897 1 GREASE FITTING
9 8520021 1 GREASE FITTING, 90
10 8036750 1 PO CHECK VALVE, (torque to 30-35 lb-ft/41-47 Nm)
11 70023898 1 PO CHECK VALVE W/THERMAL RELIEF, (torque to 30-35 lb-
ft/41-47 Nm)
12 Kit K1 1 O-RING
13 Kit K1 1 O-RING
14 Kit K1 1 O-RING
15 Kit K1 1 BACK-UP RING
16 Kit K1 1 PISTON SEAL
17 Kit K1 1 ROD SEAL
18 Kit K1 1 ROD WIPER
19 Kit K1 2 WEAR BAND
20 Kit K1 2 WEAR BAND
K1 70023899 2 SEAL KIT, (includes items 12 thru 20)
