JLG G6-42A Parts Manual User Manual
Page 431
SECTION 10 - ELECTRICAL
31200727
G10-43A,G9-43A,G6-42A
427
FIGURE 10-17. INSTRUMENT PANEL HARNESS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001102815
1
INSTRUMENT PANEL HARNESS, (includes all items)
C
1
91503105
1
8 PIN RECEPTACLE
2
91503106
1
WEDGE LOCK
3
77363228
7
TERMINAL
4
4460466
1
PLUG
5
N.S.S.
1
CONNECTOR
6
70022691
1
WEDGE LOCK
7
4460944
3
CONTACT
8
N.S.S.
1
CONNECTOR
9
N.S.S.
1
DOUBLE LOCK PLATE
10
N.S.S.
1
SOCKET
11
N.S.S.
1
WIRE SEAL
12
N.S.S.
1
PLUG
13
7026437
4
BULB BASE
14
7026438
8
TERMINAL
15
80484088
4
BULB
16
1001116816
1
DIODE
17
4460465
3
TERMINAL
18
80604021
1
WEDGE LOCK
19
4460884
1
CONNECTOR
20
4460466
1
PLUG
