SECTION 4 - ENGINE AND ATTACHING PARTS
31200727
G10-43A,G9-43A,G6-42A
119
FIGURE 4-11. EXHAUST INSTALLATION IF EQUIPPED FOR ULS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001132492
Ref
EXHAUST INSTALLATION, (G6-42A), (if equipped for ULS), (not
available to order, see items 1 thru 8 for service)
B
1001132459
Ref
EXHAUST INSTALLATION, (G9-43A & G10-43A), (if equipped for
ULS), (not available to order, see items 1 thru 8 for service)
B
1
0641610
2
HEX HD CAPSCREW, 3/8-16X1-1/4
2
0641638
2
HEX HD CAPSCREW, 3/8-16X4-3/4
3
4711600
4
WASHER, 3/8
4
24921332
1
EXHAUST CLAMP, 3IN
5
1001129560
1
DOC OUTLET PIPE
6
1001129787
1
EXHAUST CLAMP SADDLE MOUNT
7
1001130031
1
EXHAUST PIPE SUPPORT
8
1001132332
1
EXHAUST PIPE, (G6-42A)
1001120613
1
EXHAUST PIPE, (G9-43A & G10-43A)
1001131937
Ref
ENGINE POD EXHAUST INSTALLATION, (if equipped for ULS),
(not available to order, see items 101 thru 111 for service)
C
101
0641506
4
HEX HD CAPSCREW, 5/16-18X3/4
102
0641610
2
HEX HD CAPSCREW, 3/8-16X1-1/4
103
4751600
2
WASHER, 3/8
104
4891500
4
WASHER, 5/16
105
24921332
3
EXHAUST CLAMP, 3IN
106
1001127855
1
DOC AFTERTREATMENT
107
1001128363
1
DOC MOUNT BRACKET
108
1001128364
1
DOC PIPE MOUNT BRACKET
109
1001128901
1
DOC CLAMP STRAP
110
1001134241
1
HOSE WELD BRACKET
111
1001129559
1
EXHAUST FLEX PIPE, (includes item 201)
201
1001139846
1
ORIFICE PLATE
