SECTION 8 - HYDRAULIC CIRCUITS
31200727 G10-43A,G9-43A,G6-42A 303
FIGURE 8-17. AUXILIARY HYDRAULIC CIRCUIT G9-43A & G10-43A
ITEM PART NUMBER QTY DESCRIPTION REV
1 91515028 1 HOSE RETAINER ASSY, (includes items 201 thru 205) D
2 0641607 2 HEX HD CAPSCREW, 3/8-16X7/8, GR5
3 4711600 2 FLAT WASHER, 3/8
4 2171208 2 BULKHEAD, 90
5 2221254 2 ELBOW, 90, (swivel nut)
8 1001102977 1 TWIN LINE HOSE
15 1001090126 1 HOSE BRACKET
16 77133139 4 CLAMP SET
17 77133140 4 COVER PLATE
18 77133177 4 HEX BOLT, 5/16X1-3/8
19 91083217 2 CLAMP
22 1001001341 2 TUBE ASSY
26 2172108 2 ADAPTER, 90, (includes o-ring), (not shown)
141 3580346 1 HOSE PULLEY
201 91511111 1 HOSE RETAINER
202 91513026 1 PAD
203 88241023 4 FLAT HD SCREW, #10-24X5/8
204 88501612 4 HEX NUT, #10-24
205 14404102 AR LOCTITE 277
324 0641416 2 HEX HD CAPSCREW, 1/4-20X2, GR5
325 2110406 1 ADAPTER, CONNECTOR, (includes o-ring)
326 2130406 1 ADAPTER, 90, (includes o-ring)
327 2170206 1 ADAPTER, 90, (long), (includes o-ring)
328 3311401 2 HEX NUT, 1/4-20
329 4761400 2 LOCKWASHER, 1/4
330 91503112 1 DECOMPRESSION VALVE DECAL
331 1001143207 1 DECOMPRESSION VALVE MOUNT PLATE
332 1001143273 1 DECOMPRESSION VALVE
333 1001143803 2 HOSE ASSY
334 1001143809 1 HOSE ASSY
428 1001098874 2 HOSE ASSY
508 0641511 1 HEX HD CAPSCREW, 5/16-18X1-3/8, GR5
541 77133139 1 CLAMP SET
542 77133140 1 COVER PLATE
555 1001143121 1 PIPE ASSY
556 1001143122 1 PIPE ASSY
581 Ref TUBES CLAMP, (See LIFT CYLINDER CIRCUIT for Breakdown)
602 2111012 2 CONNECTOR, (includes o-ring)
610 Ref MAIN CONTROL VALVE, (See HYDRAULIC COMPONENTS
SECTION for Breakdown)
707 Ref HOSE SUPPORT, (See TILT CYLINDER AND COMPENSATING
CYLINDER CIRCUIT for Breakdown)
810 Ref HYDRAULIC INSTALLATION, (See BOOM SECTION for
Breakdown)
943 0641832 1 HEX HD CAPSCREW, 1/2-13X4, GR5
944 4761800 1 LOCKWASHER, 1/2
