SECTION 10 - ELECTRICAL
31200727 G10-43A,G9-43A,G6-42A 441
FIGURE 10-24. TILT AND AUX CONTROL MODULE
ITEM PART NUMBER QTY DESCRIPTION REV
6 4711400 2 LOCKWASHER, 1/4, (G9-43A), (if equipped with tilt on joystick)
6 4711000 2 WASHER, #10, (G10-43A), (if equipped with outrigger)
8 4761400 2 LOCKWASHER, 1/4
10 8310722 2 BUTTON HD CAPSCREW, 1/4-20X1-1/2
11 10701506 2 HEX NUT, 1/4-20
14 1001106351 1 TILT AND AUX CONTROL MODULE, (includes items 101 thru 104) E
19 Ref ACCESSORY MODULE HARNESS, (See ACCESSORY MODULE
HARNESS for Breakdown)
101 1001106352 1 ACCESSORY MODULE PC BOARD
101 4460909 2 MATING CONNECTOR
101 4460928 2 TERMINAL
101 4460916 2 PLUG
102 0861493 1 CIRCUIT CARD BOX
103 1001106353 1 TILT AND AUX DECAL
104 1001106354 1 SOFTWARE
201 Ref ACCELERATOR BRACKET, (See CONTROLS SECTION for
Breakdown)
