SECTION 5 - DRIVE TRAIN
31200727
G10-43A,G9-43A,G6-42A
153
FIGURE 5-13. CENTRAL HOUSING AND STEERING G6-42A
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1
91474507
3
O-RING
2
N.S.S.
1
INTERMEDIATE COVER
3
7029279
1
HOUSING
4
91514098
1
PLUG
5
91474512
1
VENT
7
91514188
1
PLUG
8
91474513
1
MAGNET PLUG
9
80204005
1
CIRCLIP
101
91474522
4
BOLT
104
7029528
1
STEERING CYLINDER
105
91474521
2
TIE ROD
201
91474516
2
REDUCTION BUSHING
202
91474515
1
THRUST BUSHING
203
7029282
1
FRONT SUPPORT
204
91514099
1
GREASE FITTING
205
80204117
1
PLUG
206
7029283
1
REAR SUPPORT
K1
7029282
1
FRONT SUPPORT ASSY, (includes items 201 thru 205)
K2
7029283
1
REAR SUPPORT ASSY, (includes items 201, 202 & 204 thru 206)
