JLG 110SX Parts Manual - Manual (Page 99)

3121811 3-5
S
E
C
T
I
O
N
3
B
O
O
M
SECTION 3 BOOM
6 Chain, Extend - Outer Mid BL866 Options: 1 set
1260239 100SX/110SXJ
1260235 110SX/120SXJ
1260235 110SX/110SXJ - With Inverted Power Track
7 Chain, Extend - Fly BL823 Options: 1 set
1260238 100SX/110SXJ
1260234 110SX/120SXJ
1260234 110SX/110SXJ - With Inverted Power Track
8 Chain, Retract - Fly BL446 Options: 1
1260282 100SX/110SXJ
1260275 110SX/120SXJ
1260275 110SX/110SXJ - With Inverted Power Track
9 Chain, Retract - Outer Mid BL446 Options: 1
1260237 100SX/110SXJ
1260233 110SX/120SXJ
1260233 110SX/110SXJ - With Inverted Power Track
10 3580139 Sheave - Outer Mid Extend Chain 1
11 0238927 Sheave Assembly - Fly Extend Chain A/R B
0961293 Bushing, Bronze (1 Per Sheave) A/R
12 0237151 Sheave Assembly - Outer Mid Extend Chain 2 B
0961353 Bushing, Bronze (1 Per Sheave) 2
13 0239606 Sheave Assembly - Fly Retract Chain 2 —
0961369 Bushing, Bronze (1 Per Sheave) 2
14
Adjustable Clevis Assembly - Outer Mid Retract
Chain Options: (See Figure 3-2 for Breakdown)
1
0239267 100SX/110SXJ
0239268 110SX/120SXJ
0239268 110SX/110SXJ - With Inverted Power Track
15 3421286 Pin, Attach 4
16 1360171 Clevis 1
17 3421279 Pin, Attach 1
18 3450408 Pin, Cotter 1/8" x 2" 2
19 3313002 Nut, Jam 1 1/4"-7NC 1
20 3300244 Locknut, Nylon 1 1/4"-7NC Grade 8 1
21 3312602 Nut, Jam 1"-8NC 2
22 3300243 Locknut, Nylon 1"-8NC Grade 8 2
23 0238901
Adjustable Clevis Assembly - Outer Mid Retract
Chain (See Figure 3-2 for Breakdown)
1
24 Not Used
25 Not Used
26 3421570 Pin, Attach 2
27 4751600 Flatwasher 3/8" 35
28 3450303 Pin, Cotter 3/22" x 3/4" A/R
29 0238919
Adjustable Clevis Assembly - Fly Extend Chain (See
Figure 3-2 for Breakdown)
1
30 3421280 Pin, Attach 6
31 4751000 Flatwasher #10 A/R
32 3450202 Pin, Cotter 1/16" x 1/2" A/R
33 3421629 Pin, Attach 2
34 3420659 Pin, Attach (CE Machines Only) 2
FIGURE 3-1. BOOM ASSEMBLY COMPONENTS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
