SECTION 2 TURNTABLE
FIGURE 2-7. SWING BRAKE ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0920109 SWING BRAKE ASSEMBLY (PRIOR TO S/N 64566) Ref. B
1 7011720 Shaft 1
2 7018606 Guide, Spring 1
3 7007970 Spring (Red) 6
4 7018605 Housing 1
5 Kit Plate, Separator 1
6 Kit Rotor 2
7 Kit Stator 2
8 Kit Seal, Case 1
9 7018607 Bolt, Washer Head 4
10 7011719 Cover 1
11 7018609 Plug 1
12 7007987 Pin, Dowel 2
13 Kit Seal, Oil 1
14 7011716 Ring, Retaining 1
15 Kit Bearing 1
16 7007977 Ring, Retaining 1
17 Kit Ring, Back-up (Inner) 1
18 Kit Ring, Back-up (Outer) 1
19 Kit O-Ring (Outer) 1
20 Kit O-Ring (Inner) 1
21 7018603 Piston 1
22 7007934 Gasket 2
7018608 Lining Kit (Includes Items 5,6,7,8 and 22) 1
2900766 Seal Kit (Includes items 8,13,17,18,19,20 and 22) 1
2900768 Bearing Kit (Includes Items 8,13,14,15,16 and 22) 1
0920119 SWING BRAKE ASSEMBLY (S/N 64566 TO PRESENT) Ref. A
7018612 Kit, Repair 1
Note: Repair Kit Only Ref.
