JLG 110SX Parts Manual - Manual (Page 81)

3121811 2-51
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIGURE 2-16. TANKS INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0252524 TANKS INSTALLATION Ref. 5
1 4400386
Fuel Tank Assembly
(See Items 101-112 for Breakdown)
1
2
Hydraulic Oil Tank Assembly Options:
(See Items 201-216 for Breakdown)
4400340 Standard Tank 1
4400444 Tank w/ Welder 1
3 0641614 Bolt 3/8"-16NC x 1 3/4" 4
4 4711600 Flatwasher 3/*’ 15
5 3311605 Locknut 3/8"-16NC 8
6 0641616 Bolt 3/8"-16NC x 2" 3
7 1340046 Breather 1
8 2220893 Fitting 1
9 2120134 Filter, Hydraulic 1
2120129 Element 1
— — — — — — — — — —
4300034 Stud, Weld 4
4400386 FUEL TANK ASSEMBLY Ref. 2
101 4400387 Tank Weldment 1
102 Not Used
103 2180467 Fitting, 90° 2
104 4562516 Tube, Sight 15 in./38cm
105 1320022 Clamp 2
106 2200052 Plug, Pipe - 1/4" 1
107 0100020 Sealant, Thread (Not Shown) A/R
108 4060574 Protector, Gage 1
109 3311401 Nut 1/4"-20NC 3
110 4761400 Lockwasher 1/4" 3
111 4751400 Flatwasher 1/4" 3
112 3300205 Nut, Retainer 5/16"-18NC 3
4400340 HYDRAULIC OIL TANK ASSEMBLY Ref. B
201 4400341 Tank Weldment 1
202 Not Used
203 4740338 Washer, Sealing 6
204 2420080 Gage, Level 1
7016664 Washer, Sealing 2
205 1670625 Lid 1
206 Not Used
207 3520022 Plug, Magnetic 1
208 1340045 Basket, Strainer 1
209 3960371 Gasket 1
210 3300205 Nut, Retainer 5/16"-18NC 3
211 2180606 Nipple, Pipe 1
212 2120104 Filter 1
