SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
117
4641134
Valve Assembly - Hydro Air (See Figure 1-2 for
Breakdown) (100SX & 110SX Only)
2
118
Not Used
119
4711400
Flatwasher 1/4” (Narrow)
7
120
Not Used
121
4751600
Flatwasher 3/8” (Wide)
10
122 to 123
Not Used
124
0641420
Bolt 1/4”-20NC x 2 1/2”
2
125
4641155
Valve, Junction Manifold
1
126
Not Used
127
4641165
Valve Assembly - Hydro Air (See Figure 1-2 for
Breakdown) (110SXJ & 120SXJ Only)
1
128
4641166
Valve Assembly - Hydro Air (See Figure 1-2 for
Breakdown) (110SXJ & 120SXJ Only)
1
FRAME SHIELDS INSTALLATION OPTIONS:
Ref.
0270200
2W/D
Ref.
B
0259925
4W/D
Ref.
B
201
0641404
Bolt 1/4”-20NC x 1/2”
A/R
202
0641606
Bolt 3/8”-16NC x 3/4”
8
203
3572315
Plate, Cover
A/R
204
4751600
Flatwasher 3/8"
8
205
4751400
Flatwasher 1/4"
A/R
206
4846247
Shield
2
— — — — — — — — — —
0100011
Loctite #242
A/R
FIGURE 1-1. FRAME, VALVES AND SHIELDS INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
