JLG 110SX Parts Manual User Manual
Page 67
3121811
2-37
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
86
2220063
Fitting, 90°
2
87
2220720
Fitting, Barbed
2
88
0641414
Bolt 1/4"-20NC x 1 3/4"
13
89
1320022
Clamp
4
90
0253194
Air Inlet Box Assembly
1
91
4280002
Neoprene 1/8" x 2"
30 in./76cm
92
1320059
Clamp
1
93
2180536
Fitting, Coupling
1
94
3311405
Locknut 1/4"-20NC
13
95
1060031
Cable, Battery (Small Battery to Ground)
1
96
4751500
Flatwasher 5/16"
2
97
4740362
Washer, Fender
6
98
4761500
Lockwasher 5/16"
2
99
3535949
Plate, Hose Cover
1
100
0362101
Bar, Spacer
1
101
3536008
Plate, Shield
1
102
1320021
Clamp, Muffler
1
103
4831900
Flatwasher 8mm
1
104
3790152
“O” Ring
1
0237627
ELECTRICAL PANEL ASSEMBLY
Ref.
7
201
3740059
Relay
1
202
3321001
Nut #10-32NF
3
203
3310801
Nut #8-32NC
1
204
3530425
Plate, Mounting
1
205
3740080
Relay, Sealed
1
206
3740067
Relay
2
207
3300220
Nut, Special
6
208
0641405
Bolt 1/4"-20NC x 5/8"
7
209
4791400
Starwasher 1/4"
7
210
3311401
Nut 1/4"-20NC
7
211
4711400
Flatwasher 1/4"
6
0237635
THROTTLE CABLE INSTALLATION
Ref.
4
301
0060023
Actuator
1
7008804
Bellows, Rubber
1
7008829
Board, Circuit
1
7008821
Motor, Drive
1
7008828
Cable, Throttle
1
302
0901389
Bracket, Throttle Cable
1
303
4460302
Stop, Terminal
1
304
3450203
Pin, Cotter 1/16" x 3/4"
1
305
4711400
Flatwasher 1/4" Narrow
1
306
0641409
Bolt 1/4"-20NC x 1 1/8"
2
307
4751400
Flatwasher 1/4"
2
308
0630400
Bolt, Metric 8mm - 1.25 x 90mm
2
309
4831900
Lockwasher 8mm
2
FIGURE 2-12. DEUTZ F4L-912 ENGINE INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
