3121811 2-21
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIGURE 2-6. SWING MOTOR ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
3160184 SWING MOTOR ASSEMBLY (PRIOR TO S/N 64566) Ref. B
1 Kit Seal, Dust 1
2 Kit Ring, Back-Up 1
3 Kit Seal, Lip 1
4 7004196 Valve, Rotary 1
5 7004167 Ball, Check Valve 2
6 7004179 IGR Assembly 1
7 Kit Ring, Snap 1
8 Kit Seal, Ring 3
9 7004171 Plug, Vent (Includes O-Ring) 1
10 7010780 Bolt 8
11 Not Used
12 7010781 Shaft, Spline 1
13 to 14 Not Used
15 7010782 Body/Bearing Assembly 1
16 Not Used
17 7004192 Cover/Bearing Assembly 1
18 to 20 Not Used
21 Kit Ring, Retaining 1
22 7010776 Plate, Commutator 1
— — — — — — — — — —
2900798 Seal Kit (Includes Items 1,2,3,7,8 and 21) 1
3160276 SWING MOTOR ASSEMBLY (S/N 64566 TO PRESENT) Ref. A
101 Kit Seal, Dust 1
102 Kit Ring, Back-Up 1
103 Kit Seal, Lip 1
104 Not Used
105 7004167 Ball, Check Valve 2
106 7010791 IGR Assembly 1
107 Kit Ring, Snap 1
108 Kit Seal, Ring 3
109 7010795 Plug, Vent (Includes O-Ring) 1
110 7010792 Bolt 8
111 Not Used
112 7023432 Shaft, Spline 1
113 to 114 Not Used
115 7023443 Body/Bearing Assembly 1
116 Not Used
117 7004192 Cover/Bearing Assembly 1
118 to 120 Not Used
121 Kit Ring, Retaining 1
122 7010776 Plate, Commutator 1
— — — — — — — — — —
2900798 Seal Kit (Includes Items 101,102,103,107,108 and 121) 1
