SECTION 2 TURNTABLE
FIGURE 2-3. VALVES ASSEMBLY - HYDRO AIR
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
VALVE ASSEMBLY OPTIONS: Ref.
4641065 100SX/110SX Prior to S/N 62271 Ref. E
4641181 100SX/110SX S/N 62271 to Present Ref. B
4641137 110SXJ/120SXJ Prior to S/N 62271 Ref. B
4641180 110SXJ/120SXJ S/N 62271 to Present Ref. B
1 7017482 Cartridge, Valve 1
7012518 Seal Kit - 7017482 Cartridge 1
2 7012997 Cartridge, Flow Control (Lift Down Speed Control) 1
7010545 Seal Kit - 7012997 Cartridge 1
3 Cartridge, Needle Valve/Flow Control Options: A/R
7017483 SX Models uses Cartridge, Flow Control (Not
Shown - Looks Similar to Item 4) 2
7012953 Seal Kit - 7017483 Cartridge 2
7021638
SXJ Models Uses Cartridge, Needle Valve
(Shown)
2
7012953 Seal Kit - 7021638 Cartridge 2
4 7010542 Cartridge, Load Shuttle 4
7010543 Seal Kit - 7010542 Cartridge (1 Per Cartridge) 4
5 7012914 Cartridge, Pilot Check 2
7012918 Seal Kit - 7012914 Cartridge (1 Per Cartridge) 2
6 7017484 Cartridge, Pilot Directional 2
7012942 Seal Kit - 7017484 Cartridge (1 Per Cartridge) 2
7 Cartridge, Proportional Valve (Without Coil) (Lift,
Swing, Tele, EAR & Rotate) A/R
7017485 SX Models Cartridge (Without Coil) 3
Not Available Seal Kit - 7017485 Cartridge 3
7021636 SXJ Models Cartridge (Without Coil) 3
7017495 Seal Kit - 7021636 Cartridge 3
8 7021637 Cartridge, Relief Valve (Main Pressure Adjustment) 1
7012972 Seal Kit - 7021637 Cartridge 1
9 7017487 Cartridge, Relief Valve (Lift Down Pressure) 1
7017496 Seal Kit - 7017487 Cartridge 1
10 7017421 Cartridge, Relief Valve (Swing Pressure) 1
7012998 Seal Kit - 7017421 Cartridge 1
11 7017418 Cartridge, Relief Valve (EAR Up Pressure) 1
7012998 Seal Kit - 7017418 Cartridge 1
12 7017488 Cartridge, Relief Valve (EAR Down Pressure) 1
7012998 Seal Kit - 7017488 Cartridge 1
13 7017422 Cartridge, Relief Valve (Rotate Right, Rotate Left) 2
7012998 Seal Kit - 7017422 Cartridge 2
14 7017489 Cartridge, Relief Valve (Level Down Pressure) 1
7012998 Seal Kit - 7017489 Cartridge 1
15 7017422 Cartridge, Relief Valve (Level Up Pressure) 1
7012998 Seal Kit - 7017489 Cartridge 1
16 7012910
Cartridge, Solenoid Valve (Without Coil) (Main
Dump)
1
2900708 Seal Kit - 7012910 Cartridge 1
17 7010635 Cartridge, Solenoid Valve (Without Coil) (Lift Down) 1
2900708 Seal Kit - 7010635 Cartridge 1
