JLG 110SX Parts Manual - Manual (Page 55)

3121811 2-25
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIGURE 2-8. SWING HUB ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
2780116 SWING HUB ASSEMBLY Ref. —
1 7001916
Hub and Spindle Assembly
(See Items 101-111 for Breakdown)
1
2 7001917 Gear, Internal 1
3 7001918 Carrier Assembly (See items 201-207 for Breakdown) 1
4 7000279 Gear, Ring 1
5 Kit O-Ring 2
6 7001920 Cover 1
7 Not Used
8 7001922 Washer, Thrust 1
9 Not Used
10 Not Used
11 Not Used
12 Not Used
13 7001921 Gear, Input 1
14 Not Used
15 7000287 Washer, Thrust 4
16 7000288 Bearing, Thrust 2
17 7001923 Bolt 8
18 7001924 Bolt, Shoulder 4
19 7001929 Lockwasher 4
20 7001926 Plug, Pipe 1
7001916 HUB AND SPINDLE ASSEMBLY Ref.
101 7001982 Shaft, Output 1
102 Kit Seal, Lip 1
103 7000272 Cup, Bearing 1
104 7000273 Cone, Bearing 1
105 7000274 Cup, Bearing 1
106 7000275 Cone, Bearing 1
107 Not Available Hub 1
108 Kit Spacer 1
109 Kit Ring, Retaining 1
110 7001928 Plug, Pipe 1
111 7001926 Plug, Pipe 2
7001918 CARRIER ASSEMBLY Ref.
201 Not Available Housing, Carrier 1
202 Kit Washer, Thrust 6
203 7001902 Bearing, Needle 84
204 Kit Spacer 3
205 7001904 Shaft, Planet 3
206 Kit Gear, Cluster 3
207 Kit Rollpin 3
2900202 Seal Kit (Includes Items 5, 102, 108 and 109) 1
7001927 Cluster Gear Kit (Includes Items 202, 204,206 and 207) 1
