2-38 3121811
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
310 3290801 Nut, Metric 8mm - 1.25 2
311 1320041 Clamp 1
312 4761400 Lockwasher 1/4" 3
313 4751600 Flatwasher 3/8" 2
314 0641406 Bolt 1/4"-20NC x 3/4" 1
315 3311401 Nut 1/4"-20NC 1
0270271 EXHAUST INSTALLATION Ref. 1
401 4751400 Flatwasher 1/4" 4
402 3220082 Muffler 1
403 0340041 Band, Mounting 1
404 0901849 Bracket, Exhaust Mounting 1
405 0641408 Bolt 1/4"-20NC x 1" 2
406 3311405 Locknut 1/4"-20NC 2
407 0641408 Bolt 1/4"-20NC x 1" 4
408 4751400 Flatwasher 1/4" 4
409 3311405 Locknut 1/4"-20NC 4
410 1120423 Cap, Rain 1
411 4844235 Stack, Exhaust 1
412 4565751 Tube, Exhaust 1
413 1320011 Clamp, Muffler 2
3600208 AUXILIARY PUMP ASSEMBLY Ref. A
501 7013711 Coupling 1
502 7013710 Motor 12VDC 1
7013753 Brush Kit 1
503 7013712 Pump 1
3600468 AUXILIARY PUMP ASSEMBLY Ref. A
551 7011016 Coupling 1
552 7011003 Motor 12VDC 1
553 70001108 Replacement Pump Kit (Includes all Items Below) 1
7012576 Bracket, Mounting
7011044 Gasket, Mounting
7011016 Coupling
70000969 Seal, Shaft
Use Item 553 Stator
70001079 Cap Assembly
70001076 Spring
70001081 Ball
70001080 Seat
7011024 Seal
7011048 Washer
7011043 Screw
70000970 Ring, Retaining
70000971 Gear
FIGURE 2-12. DEUTZ F4L-912 ENGINE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
