JLG 110SX Parts Manual User Manual
Page 34
2-4
3121811
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
118
4751600
Flatwasher 3/8"
A/R
119
4761600
Lockwasher 3/8"
A/R
120
3311601
Nut 3/8"-16NC
A/R
121
Pin, Bottom Master Cylinder Options:
1
3422068
100SX/110SX
3420085
110SXJ/120SXJ
122
3450610
Pin, Cotter 3/16" x 2 1/2"
(Not Required on 100SX/110SX)
2
123
Pin, Bottom Lift Cylinder Options:
1
3421676
100SX/1110SX/120SXJ
3421676
110SX - Australian Spec (With Inverted Track)
3422149
110SXJ - Australian Spec (With Inverted Track)
3422149
110SXJ - CE Spec
3421676
110SXJ - Australian Spec
124
4712200
Flatwasher 3/4"
2
125
4762200
Lockwasher 3/4"
2
126
0682213
Bolt 3/4"-10NC x 1 5/8" (Grade 8)
2
127
Pin, Top Lift Cylinder Options:
1
3421678
100SX/110SX/110SXJ/120SXJ
3421678
110SX - Australian Spec (With Inverted Track)
3421678
110SXJ - Australian Spec (With Inverted Track)
(Prior to S/N 55965)
3422150
110SXJ - Australian Spec (With Inverted Track)
(S/N 55965 to Present)
128
4740361
Washer, Special
2
129
3900159
Screw, Countersunk 1/2"-13NC x 3/4"
4
130
0641840
Bolt 1/2"-13NC x 5"
1
131
3311805
Locknut 1/2"-13NC
1
132
2160001
Fitting, Grease - 90°
1
133
4740040
Flatwasher, Special (Not Required on 100SX/110SX)
2
— — — — — — — — — —
0100019
Loctite #271
A/R
0270235
HORIZONTAL CUTOUT LIMIT SWITCH INSTALLA-
TION (RIGHT SIDE)
Ref.
3
201 to 215
Not Used
216
4360301
Switch, Limit
1
217
3910812
Screw #8-32NC x 3/4"
2
— — — — — — — — — —
0100011
Loctite #242
A/R
0239843
LUBE LINES INSTALLATION (100SX/110SX)
Ref.
A
0239844
LUBE LINES INSTALLATION (110SXJ/120SXJ)
Ref.
3
301
2160002
Fitting, Grease
3
302
2220001
Fitting
3
303
Hose Options:
1
2750528
100SX/110SX
2751032
110SXJ/120SXJ
FIGURE 2-1. TURNTABLE, BOOM AND SWITCHES INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
