1-16 3121811
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
55 Kit 4 Spring, Pressure 1
56 to 59 Not Used
60 7022572 Spindle 1
61 7022573 Piston 1
62 7022574 Coupler 1
63 7022575 Ring, Locator 1
64 7021354 Plate, Back-up 1
65 7022576 Plate, Back-up 1
66 7022577 Ring, Retaining 1
67 7022578 Ring, Retaining 1
68 7022509 Ring, Retaining 1
69 7022579 Bolt 2
70 to 71 Not Used
72 Kit 5 Disc, Brake 4
73 Kit 5 Disc, Brake 5
74 Kit 5 Spring A/R
75 Kit 6 Ring, Back-up 2
76 Kit 6 Seal 1
77 Kit 6 Ring, Back-up 2
78 Kit 6 Seal 1
79 to 84 Not Used
85 7024031 O-Ring 1
86 Not Used
87 7024032 O-Ring 1
88 to 119 Not Used
120 3160248 Motor, Hydraulic 1
— — — — — — — — — —
7024028 Kit 1 - Planet Bearing Kit (Includes Items 1, 11 & 15) 1
7024029 Kit 2 - Planet Bearing Kit
(Includes Items 2, 10, 14 & 17) 1
7022536 Kit 3 - Bearing Kit (Includes Items 4, 12, 23, & 53) 1
7022540 Kit 4 - Mechanical Disconnect Kit
(Includes Items 13, 22, 33, 43, 44, 54 & 55) 1
7022580 Kit 5 - Brake Disc Kit (Includes Items 72-74) 1
7022581 Kit 6 - Brake Seal Kit (Includes Items 75-78) 1
7024030 Kit 7 - Planet Gear Kit
(Includes Items 40, 46, 48 & 50) 1
FIGURE 1-5. DRIVE HUB ASSEMBLY (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
