JLG 110SX Parts Manual - Manual (Page 69)

3121811 2-39
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
70001112 Shaft, Idler
70001065 Pin, Drive
70000976 Bearing, Needle
7010911 Pin, Dowel
70001085 Gasket
Use Item 553 Housing, Gear
Not Available Label
70001106 Screw
70001107 Shaft, Drive
Use Item 200B Plug
0270293 ENGINE DISTRESS INSTALLATION Ref. 1/A
601 4360179
Switch, Temp Head (Not Shown)
(Located Under Top Engine Cover)
1
602 to 604 Not Required
0270834 LOW OIL PRESSURE SHUTDOWN INSTALLATION Ref. 1
701 Not Used
702 3740080 Relay 1
ENGINE COMPONENTS Ref.
7000663 Alternator (Bosch) 1
7000872 Alternator (Delco-Remy) 1
7000661 Starter 1
7000700 Manifold, Exhaust 1
7000697 Belt, Blower 1
7000698 Belt, Alternator 1
7000699 Gasket, Doughnut Exhaust 1
7026125 Counter/Exhaust Flange (3 Hole) 1
7014686 Engine Kit (includes 12 each of 3 Different Fuel Line
Washers, 1 each of Oil Plug Washer, Oil Filter and
Fuel Filter)
Use 7029274 Filter, Fuel (was p/n 7000649) 1
Use 7029276 Filter, Oil (was p/n 7000648) 1
7014503 Filter, Oil (Case of 12) 1
70002252 Ring, Head Fire 4
70002253 Gasket Set (Complete Engine) 1
70002254 Kit, Piston/Cylinder 4
70002258 Bolt, Cylinder Head 4
70002259 Washer, Cylinder Head Bolt 4
70001361 Pump, Fuel Injection 4
70001927 Manifold, Exhaust 1
70001928 Gasket, Exhaust Manifold 4
7016330 Switch, Oil Pressure 1
7019607 Solenoid, Fuel Shutdown 1
7016364 Pump, Fuel Lift 2
7020208 Gear, Ring 1
FIGURE 2-12. DEUTZ F4L-912 ENGINE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
