3121811 2-35
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIGURE 2-12. DEUTZ F4L-912 ENGINE INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0270272 DEUTZ F4L-912 ENGINE INSTALLATION Ref. 2
1 2000083 Engine - Deutz Diesel F4L-912 1
2000115 Engine - Deutz Diesel F4L-912 - Clean Burn 1
2 3600260
Pump Assembly - Sunstrand
(See Figure 2-15 for Breakdown)
1
3 3200229 Motor Support Weldment (Front) 1
4 3200228 Motor Support Weldment (Rear) 2
5 3200133 Mount, Rubber Motor (Front) 1
6 3200183 Mount, Rubber Motor (Rear) 2
7 3200227 Plate, Engine Mounting (Front) 1
8 3200306 Plate, Engine Mounting (Rear) 1
9 3600286
Pump Assembly - Barnes
(See Figure 2-16 For Breakdown)
1
10 0901829 Bracket, Filter 1
11 2120135 Filter - Charge Pump 1
2120136 Element 1
12 1060044 Cable, Battery (Starter to Ground) 1
13 0641812 Bolt 1/2"-13NC x 1 1/2" 2
14 4761800 Lockwasher 1/2" 2
15 0250069 Fuel Shutdown Kit (Includes Mounting Hardware) 1
16 0642032 Bolt 5/8"-11NC x 4" 3
17 3312005 Locknut 5/8"-11NC 3
18 4740242 Flatwasher, Special 3
19 0701427 Bolt, Metric 14mm x 100mm 4
20 4740191 Lockwasher, Metric 14.2mm 4
21 0701215 Bolt, Metric 12mm x 35mm 8
22 4832100 Lockwasher 12mm 8
23 4891600 Flatwasher 3/8" 2
24 0641620 Bolt 3/8"-16NC x 1 1/4" 2
25 0100011 Loctite #242 (Not Shown) A/R
26 0701015 Bolt, Metric 10mm x 35mm 2
27 4831700 Lockwasher 6mm 1
28 3311401 Nut 1/4"-20NC 3
29 0641405 Bolt 1/4"-20NC x 5/8" 4
30 4761400 Lockwasher #1/4" 4
31 Not Used
32 0700617 Bolt, Metric 6mm x 45mm 5
33 0237627
Electrical Panel Assembly
(See Items 201-211 for (Breakdown)
1
34 0237635
Throttle Cable Installation
(See Items 301-315 for Breakdown)
1
35 4640742 Valve, Oil Drain 1
36 2720042 Hose, Heater 6 in./15cm
37 4832000 Lockwasher, Metric 10mm 2
38 3290607 Locknut, Metric 6mm 4
39 1320222 Clamp (Not Shown) 3
40 4360490 Switch, Oil Pressure 1
41 4811700 Flatwasher 6mm 9
42 4843384 Air Intake Weldment 1
