3121811 2-7
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIGURE 2-2. VALVES INSTALLATION - TURNTABLE MOUNTED
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
VALVES INSTALLATION - TURNTABLE MOUNTED Ref.
0270353 VALVES INSTALLATION - 100SX/110SX Ref. D
0259923 VALVES INSTALLATION - 110SXJ/120SXJ Ref. F
1 Not Used
2 0140001 Horn 1
3 0641406 Bolt 1/4"-20NC x 3/4" 1
4 Not Used
5 0641607 Bolt 3/8"-16NC x 7/8" 3
6 Not Used
7 0641616 Bolt 3/8"-16NC x 2" 4
8 Not Used
9 3311401 Nut 1/4"-20NC 3
10 3311605 Nut 3/8"-16NC 4
11 3535942 Plate, Valve Mounting 1
12 to 17 Not Used
18
Valve Assembly - Hydro-Air Options:
(See Figure 2-3 for Breakdown)
1
4641065 100SX/110SX (Prior to S/N 62271)
4641181 100SX/110SX (S/N 62271 to Present)
4641137 110SXJ/120SXJ (Prior to S/N 62270)
4641180 110SXJ/120SXJ (S/N 62270 to Present)
19 4711400 Flatwasher 1/4" (Narrow) 5
20 4711600 Flatwasher 3/8" (Narrow) 8
21 4751600 Flatwasher 3/8" (Wide) 3
22 4761400 Lockwasher 1/4" 3
23 to 25 Not Used
26 4641079 Valve, Counterbalance 1
7010123 Cartridge 1
2900770 Seal Kit 1
27 to 28 Not Used
0270397
LIFT DOWN HOLDING VALVE INSTALLATION
(100SX/110SX/110SXJ WITH OUT JACKS ONLY)
Ref. B
101 0641516 Bolt 5/16”-18NC x 2” 2
102 2220373 Fitting, Straight 1
103 2220582 Fitting, Straight 1
104 2220600 Fitting, Straight 2
105 2220683 Fitting, 45° 1
106 2221061 Fitting, Tee 1
107 2752435 Hose 1
108 2752498 Hose 1
109 3311505 Locknut 5/16”-18NC 2
110 4640521 Valve, Control 1
7004281 Cartridge 1
7004282 Seal Kit 1
111 4711500 Flatwasher 5/16” (Narrow) 4
