1-10 3121811
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
110 0641436 Bolt 1/4"-20NC x 4 1/2" 4
111 0641607 Bolt 3/8"-16NC x 7/8" 16
112 0641612 Bolt 3/8"-16NC x 1 1/2" 4
113 0641808 Bolt 1/2"-13NC x 1" 26
114 0641812 Bolt 1/2"-13NC x 1 1/2" 6
115 0641816 Bolt 1/2"-13NC x 2" 6
116 0641820 Bolt 1/2"-13NC x 2 1/2" 6
117 0642014 Bolt 5/8"-11NC x 1 3/4" 4
118 0642010 Bolt 5/8"-11NC x 1 1/4" 18
119 0961950 Bearing 4
120 1120465 Cap 16
121 1683920
Axle Extension Cylinder Assembly
(See Section 5 for Breakdown)
2
122 3310805 Locknut #8-32NC 8
123 3311405 Locknut 1/4”-20NC 12
124 3311605 Locknut 3/8"-16NC 28
125 3312002 Nut, Jam 5/8"-11NC 4
126 3312602 Nut, Jam 1"-8NC 16
127 3340888 Wear, Pad Assembly 8
128 3422689 Pin 2
129 3422818 Pin 2
130 3572340 Plate 2
131 3572346 Plate, Switch Mount 4
132 3572347 Angle, Switch Mount 4
133 3841143 Keeper, 3/8” 4
134 3900219 Set Screw 4
135 3900292 Set Screw 12
136 3930820 Bolt #8-32NC x 1 1/4” 8
137 4070772 Shim 12
138 4071001 Shim, Axle Stop 7
139 4360322 Switch, Limit 4
140 4711800 Flatwasher 1/2” (Narrow) 38
141 4751400 Flatwasher 1/4” (Wide) 8
142 4751600 Flatwasher 3/8” (Wide) 8
143 4752000 Flatwasher 5/8” (Wide) 18
144 4846176 Outer Axle Weldment A/R
145 4846177 Inner Axle Weldment A/R
146 4846219
Inner Axle Weldment
(110SX/110SXJ 4WD/2WS Rear Only)
1
147 4846220
Outer Axle Weldment
(110SX/110SXJ 4WD/2WS Rear Only)
1
148 4846226 Hose Carrier Weldment (LF, RR) 2
149 4846227 Hose Carrier Weldment (RF, LR) 2
150 Not Used
151 4460428
Connector, Strain Relief
(110SX/110SXJ 4WD/2WS Only)
4
152 3951804 Set Screw, Knurled Cup Point 1/2” x 1/2”
— — — — — — — — — —
0100011 Loctite #242 A/R
0100079 Sealant, Pipe A/R
FIGURE 1-3. STEERING AND AXLES INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
