JLG 110SX Parts Manual - Manual (Page 63)

3121811 2-33
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIGURE 2-11. REMOTE DRIVE CONTROL BOX ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0270048 REMOTE DRIVE CONTROL BOX ASSEMBLY Ref. 2/C
1 0861354 Box, Remote 1
2 3572216 Plate, Remote Box Lid 1
3 4420037 Tape, Insulation A/R
4 1704528 Decal, Remote Box 1
5 1701775 Decal, Potentiometer 1
6 4360475 Switch, Emergency Stop 1
7 4060802 Shield, Toggle 6
8 4360314 Switch, Toggle 3
9 4360340 Switch, Potentiometer 1
10 3300352 Nut, Special 1
11 4460425 Connector, Strain 1
12 4360331 Switch, Toggle 1
13 4360345 Switch, Toggle 1
14 1060306 Cable, Control 16/16 25 ft.
15 4740120 Washer, Nylon 4
16 3300177 Nut, Tinnerman #8 4
17 0750804 Screw #8 x 1/2 Lg. 4
18 2560116 Knob, Speed Control (Black) 1
19 4711600 Flatwasher 3/8" 1
— — — — — — — — — —
3730091 Resistor (Not Shown) 1
3990001 Diode (Not Shown) 10
