2-12 3121811
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
18 7017452 Cartridge, Solenoid Valve (Without Coil) (Telescope) 1
7017402 Seal Kit - 7017452 Cartridge 1
7012944 Coil - 12V 2
19 Bosch Valve Section - Complete (Lift) Options: A/R
7021622 SX Models Valve Section - Complete 1
7021405 Spool (2 Per Section) 1
7021401 Coil (2 Per Section) 1
7021402 Seal Kit (2 Per Section) 1
7021406 Cap, End (2 Per Section) 1
7017491 SXJ Models Valve Section - Complete 1
7021404 Spool (2 Per Section) 1
7021401 Coil (2 Per Section) 1
7021402 Seal Kit (2 Per Section) 1
7021403 Cap, End (2 Per Section) 1
20 7017491 Bosch Valve Section - Complete (Swing) 1
7021404 Spool (2 Per Section) 1
7021401 Coil (2 Per Section) 1
7021402 Seal Kit (2 Per Section) 1
7021403 Cap, End (2 Per Section) 1
21 7017491 Bosch Valve Section - Complete (EAR) 1
7021404 Spool (2 Per Section) 1
7021401 Coil (2 Per Section) 1
7021402 Seal Kit (2 Per Section) 1
7021403 Cap, End (2 Per Section) 1
22 7017490 Bosch Valve Section - Complete (Rotate) 1
7021400 Spool (2 Per Section) 1
7021401 Coil (2 Per Section) 1
7021402 Seal Kit (2 Per Section) 1
7021403 Cap, End (2 Per Section) 1
23 7017491 Bosch Valve Section - Complete (Level) 1
7021404 Spool (2 Per Section) 1
7021401 Coil (2 Per Section) 1
7021402 Seal Kit (2 Per Section) 1
7021403 Cap, End (2 Per Section) 1
24 7012944 Coil 2
25 7012943 Coil 2
26 7017451 Coil 3
27 7017492 Orifice 1
28 7017493 Orifice 1
29 7017494 Orifice 2
30 Cartridge, Check Valve Option: A/R
Not Required SX Models 0
7021639 SXJ Models Uses Check Valve 1
2900756 Seal Kit - 7021639 Cartridge 1
31 Block, Manifold A/R
Not Required SX Models 0
Not Available SXJ Models Uses Manifold 1
7021640 Seal Kit - Manifold Mounting 1
32 7024827 Screw (SXJ Rotate Section Only) A/R
FIGURE 2-3. VALVES ASSEMBLY - HYDRO AIR (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
