70
For Thermal printer DPU-414 e.g. for Matrix printer
Seikosha SP 2400
(endless paper)
DIP SW
settings
Dip SW-1 Dip SW-1
1 (OFF) : Input = Serial
2 (ON) : Printing Speed = High
3 (ON) : Auto Loading = ON
4 (ON) : Auto LF = ON
5 (ON) : Setting Command
= Enable
6 (OFF) : Printing
7 (ON) : Density
8 (ON) : = 100 %
1 (OFF) : USA
2 (OFF) : USA
3 (OFF) : USA
4 (ON) : IBM
5 (OFF) : Character Set 1
6 (ON) : 12 inches
7 (OFF) : LF only
8 (ON) : CR = CR + LF
Dip SW-2 Dip SW-2
1 (OFF) : Printing Columns = 80
2 (ON) : User Font Back-up
= ON
3 (ON) : Character Select
= Normal
4 (OFF) : Zero = Slash
5 (ON) : International
6 (ON) : Character
7 (ON) : Set
8 (OFF) : = USA
1 (ON) : 9600 Baud
2 (ON) : 9600 Baud
3 (ON) : XON/XOFF
4 (OFF) : No Parity
5 (OFF) : No Parity
6 (OFF) : 8 bits
7 (ON) : Serial
8 (OFF) : No single sheet
Dip SW-3
1 (ON) : Data Length = 8 bits
2 (ON) : Parity Settings = No
3 (ON) : Parity Conditions
= Odd
4 (OFF) : Busy Control
= XON/XOFF
5 (OFF) : Baud
6 (ON) : Rate
7 (ON) : Select
8 (ON) : = 9600 bps
4 Device description
