73
Operation
TransferMan ® 4r
English (EN)
6.17 Function function
Function allows you to reset the parameters and coordinates and to move the modules to
the middle position.
6.17.1 Function menu and parameters
Abb. 6-7:Menu –
Fig. 6-7: Menu – Function
6.17.2 Executing Zero coordin.
1. Select the parameters and confirm with Enter .
2. Confirm Execute with Enter .
• All coordinates are reset to zero.
• Saved positions are deleted.
• Set limits are deleted.
6.17.3 Executing Center motors
Prerequisites
• No capillary holder is clamped.
1. Select the parameters and confirm with Enter .
2. Confirm Execute with Enter .
• X-motor and Y-motor are moved to the middle position.
Parameter Value Range of values
Zero coordin. Reset all coordinates to zero Execute
Center motors Move step motors of the motor module to the middle
position Execute
User default Reset the settings to the delivery status Execute
CAUTION! Risk of crushing between the modules
The modules automatically move in all spatial axes.

Do not reach into the movement range of the modules.
