Installation
TransferMan

English (EN)

4.6.1

Inserting Femtotips

1. Remove the grip head.

2. Screw the adapter for Femtotips into the universal capillary holder.

3. Screw the Femtotip into the adapter and tighten.

4.7

Setting the injection angle

Standard capillary: Only use the 0 grip head with capillaries with an outer
diameter of 1.0 mm to 1.1 mm. If you would like to use other capillaries, order
the matching grip head.

1. Push the capillary into the grip head

until it reaches the stop and tighten the
grip head.

1. Turn the knurled screw to set the

injection angle.
