Eppendorf TransferMan4 r - Manual (Page 67)

67
Operation
TransferMan ® 4r
English (EN)
6.13.3 Move the capillary out with the home key
Prerequisites
• The parameters in the
Home menu have been defined.
6.13.4 Move the capillary back with the home key
1. Press the home key.
• The capillary is moved back into the work area.
• The
home function is terminated.
6.13.5 Setting the offset.
For capillaries of different lengths, an offset can be set. This defines a limit for the home
function.
CAUTION! Risk of crushing between the modules
The modules automatically move in all spatial axes.

Do not reach into the movement range of the modules.
1. Press the home key.
The home key flashes.
• The capillary is moved out of the work
area.
• The home key lights up.
CAUTION! Risk of crushing between the modules
The modules automatically move in all spatial axes.

Do not reach into the movement range of the modules.
1. Change the offset using the arrow keys.
• The value for the offset is displayed in
the status field.
