71
Operation
TransferMan ® 4r
English (EN)
6.15.2 Execute the PiezoXpert function
Prerequisites
• A PiezoXpert is connected.
1. Activate Synchr. PiezoXp.
2. Set PiezoXp. speed .
3. Set PiezoXp. dist.
4. Select PiezoXp. axial .
5. Close the menu.
6. Trigger the function with
Channel A on the PiezoXpert.
• The function is executed.
6.16 Installation function
The function provides settings for making fine adjustments to the motor module and the
control board. Parameters in the
Installation menu override identical softkey functions.
6.16.1 Installation menu and parameters
Abb. 6-6:Menu –
Fig. 6-6: Menu – Installation
6.16.2 Installation parameters
Parameter Value Range of values Increment Standard
Side Set the mounting side LEFT/RIGHT – RIGHT
Angle Set the capillary angle in
degrees 0° – 90° 1 –
