P/N 27-0000T - 29 spl. DODGE Gas NV4500 to Chevy V6 & V8 Adapter plate design
The overall assembly length is 26.125”. These kits require the use of a stock GM bellhousing with a 5.125” index
diameter. These kits use an adapter plate that couples the Dodge transmission to a standard GM bellhousing. We have included
a mounting bracket for the stock Jeep mechanical clutch linkage. If your vehicle is equipped with a hydraulic clutch, a bracket will
need to be fabricated. The drawing on the following page shows the new index retainer for the Dana 300 transfer case. These
kits also include a crossmember mount & spacer to properly support the transmission onto the stock crossmember. The stock
crossmember will require some modifications, and a body lift is recommended.
This kit include: This kit include: This kit include: This kit include: This kit include:
P/N 712550 - Adapter plate kit
(For clutch components, refer to the GM Adapter Plate section of this manual)
P/N 716021 - Crossmember mount for Dana 300
P/N 716048 - Crossmember spacer
P/N 716221 - Retainer kit
P/N 716638 - Jeep clutch pivot
P/N 716050D1 - Shifter handle assembly
P/N 52-0229 - 29 spline Dana 300 input
P/N 27-0001T - 29 spl. DODGE Gas NV4500 to Chevy V6 & V8 Full bellhousing design
The overall length is 25.125”. These kits use an new custom bellhousing that bolts to the GM engine. The stock Jeep clutch torque
tube bracket can be mounted directly to our bellhousing. This bellhousing also has provisions for a stock Jeep Iron Duke slave
cylinder. The drawing on the following page shows the new index retainer for the Dana 300 transfer case. These kits also include
a crossmember mount & spacer to properly support the transmission onto the stock crossmember. The stock crossmember will
require some modifications, and a body lift is recommended. Refer to
Page 47 for more information on the 712576 bellhousing
kit.
This kit include: This kit include: This kit include: This kit include: This kit include:
P/N 712576 - Bellhousing kit
P/N 716021 - Crossmember mount for Dana 300
P/N 716048 - Crossmember spacer
P/N 716221 - Retainer kit
P/N 716050D1 - Shifter handle assembly
P/N 52-0229 - 29 spline Dana 300 input
The recommended clutch components for the bellhousings listed above are found in the GM Full Conversion Bellhousing section
of this manual.
This kit is designed for our NV4500 trans-
mission P/N 26-0029RGM. If you are obtain-
ing your own transmission, you will need to
order a new input shaft to work with the
bellhousing.
P/N 52-0221 - GM input shaft.
