PO Box 247, 4320 Aerotech Center Way Paso Robles, CA 93447
PH: 800.350.2223 F: 805.238.4201 www.advanceadapters.com
P/N: 712543J
PAGE: 1 OF 4
PAGE REV. DATE:
4/02/14
KIT CONSISTS OF:
No. QTY Part No. Description
Special Note: The components packaged in this kit have been assembled and machined for specific types of conversions. Modifications to any of
the components will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required
to complete your conversion, we strongly recommend that you contact our sales department for more information. This instruction sheet is only
to be used for the assembly of Advance Adapter components. We recommend that a service manual pertaining to your vehicle be obtained for
specific torque values, wiring diagrams and other related equipment. These manuals can be found online, at dealerships and parts stores.
AX15 TO AMC JEEP ADAPTER
1
1 711543
ADAPTER- FORD SMALL BLOCK TO JP AX15
2
1 716742
SEAL-TOYOTA AX15 RETAINER
3
8 720040
S.H.C.S. 8mm X 1.25 X 20mm
4
4 723113
S.H.C.S. 5/16”-18 X 7/8” LG
5
1 761019
BRG. RETAINER FORD (4.848”)
6 1 716164
.750 PILOT TIP/AMC BLOCK 1.818
7
9 720030
10mm X 1.25 X 30mm S.H.C.S.
8
1 724317
S.H.C.S. 7/16”-14 X 1-1/4”
4
9
1 LC383271 10-1/2” CLUTCH DISC. 1-1/8
This adapter plate is designed to retain the stock Jeep bellhousing off of a T176 or T150 transmission.
These two bellhousings both have a transmission bolt pattern similar to a Ford transmission. If you
have a T5, T4 or SR4 bellhousing, you can drill the bellhousing to fit our adapter plate providing the
bellhousing has material. If you require a new bellhousing, the Jeep part number is 8133951 or the
Advance Adapters part number is 712599. By retaining this stock bellhousing, the stock clutch linkage
can be retained
.
This kit can be installed with the transmission and transfer case remaining in the vehicle. However, it
will prove to be an easier installation if the transmission and transfer case are removed and the new
engine and AX15 assembly are installed as one unit.
