48
Brocade DCX 8510-4 Backbone Hardware Reference Manual
53-1002177-05
Determining the status of a port, application, or encryption blade
4
describes the port and application blade LED patterns and the recommended actions for
those patterns.
TABLE 3
Port and application blade LED descriptions
LED purpose
Color
Status
Recommended action
Power LED
Steady green
Blade is enabled.
No action required.
No light (LED is off)
Blade is not powered on.
Ensure that the blade is firmly
seated and either the
thumbscrew is fully engaged or
the slider is pushed up and the
ejectors are fully engaged.
Status LED
No light (LED is off)
Blade is either healthy or does
not have power.
Verify that the power LED is on.
Steady amber
Blade is faulty.
Ensure that the blade is firmly
seated and check the status by
entering the slotShow
command. If LED remains
amber, consult the Brocade
DCX 8510-4 supplier.
Slow-flashing amber (on 2
seconds, then off 2
seconds)
Blade is not seated correctly or
is faulty.
Pull the blade out and reseat it.
If LED continues to flash,
replace the blade.
Fast-flashing amber (on
1/2 second, then off 1/2
second)
Environmental range exceeded.
Check for out-of-bounds
environmental condition and
correct it.
