Brocade DCX 8510-4 chassis removal and replacement
5
FID
1 | 1 | 1 | 1 | 1 | 128 | 128 | 128 | 128 | 128 |
switch:admin>
2. Determine any differences between the information in the SANafter.txt file and the information
in the SANbefor.txt file created earlier. In particular, look for differences in the following:
•
Device types
•
Number of devices
•
ISL and port states
•
Number of switches in the fabric
3. Resolve any issues or unintentional changes to the Brocade DCX 8510-4 or fabric:
•
If there are any mechanical problems, try reseating the associated component.
•
If the configuration information is not correct for the Brocade DCX 8510-4, modify as
required.
•
If other issues exist, contact your support provider.
Cable routing table
is a 64-port template for a cable routing table. Make copies of the table to cover the total
number of ports in the Brocade DCX 8510-4.
TABLE 12
Cable routing table for Brocade DCX 8510-4 (64 ports shown)
Slot/port
Cable labels
Connected device
Slot/port of device
Slot
Port
Switch end
Device end
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
