Brocade DCX 8510-4 Backbone Hardware Reference Manual 109
53-1002177-05
Appendix
A
Specifications
In this appendix
• General specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
• System architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
• System size and weight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
• System blade and FRU weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
• Facility requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
• Environmental requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
• Fibre Channel port specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
• Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
• Power cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
• Data transmission ranges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
• Qualified cables for the FC8-64 port blade . . . . . . . . . . . . . . . . . . . . . . . . . 120
• Safety notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
• Regulatory compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
• Environmental regulation compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
General specifications
The Brocade DCX 8510-4 is compliant with United States and International safety and
Electromagnetic Compatibility (EMC) standards.
Table 13 lists the general specifications for the
Brocade DCX 8510-4.
TABLE 13 General specifications
Specification Description
Configurable port types F_Port, E_Port, EX_Port, M_Port, D_Port
System architecture Nonblocking shared memory
System processor FreeScale 8548, 1.2 GHz
ANSI Fibre Channel protocol FC-PH (Fibre Channel Physical and Signalling Interface standard)
Classes of service Class 2, Class 3, Class F (interswitch frames)
Fabric initialization Complies with FC-SW 5.0
FC-IP (IP over Fibre Channel) Complies with FC-IP 2.3 of the FCA profile
