Infinity Supported Application
15
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware
Reference
7100-XXXX-62
7101-XXXX-63
Function
Dest.
Pin
Evo
VIII
Dest.
Pin
Evo IX
Hardware Specification
Notes
C1-55
Power Ground
Ground
Power Ground
Connect directly to battery ground.
C1-56
Injector 6
Injector 6
Saturated or peak and hold, 3A
max continuous
Injector 6
C1-57
Injector 5
Injector 5
Saturated or peak and hold, 3A
max continuous
Injector 5
C1-58
Injector 4
Injector 4
15
2
Saturated or peak and hold, 3A
max continuous
Injector 4
C1-59
Injector 3
Injector 3
2
24
Saturated or peak and hold, 3A
max continuous
Injector 3
C1-60
Power Ground
Ground
26
58
Power Ground
Connect directly to battery ground.
C1-61
+12V
+12V In
25
47
12 v olt power f rom relay
12 v olt power f rom relay . Relay must
be controlled by +12V Relay Control
signal, pin C1-29 abov e.
C1-62
Injector 2
Injector 2
14
9
Saturated or peak and hold, 3A
max continuous
Injector 2
C1-63
Injector 1
Injector 1
1
1
Saturated or peak and hold, 3A
max continuous
Injector 1
C1-64
+12V
+12V In
12
59
12 v olt power f rom relay
12 v olt power f rom relay . Relay must
be controlled by +12V Relay Control
signal pin C1-29 abov e.
C1-65
+12V_SW
Ignition Switch
82
99
10K pulldown
Full time battery power must be
av ailable at C1-10 bef ore this input is
triggered.
C1-66
Analog_In_Temp_1
Coolant Temp
Sensor
83
44
12 bit A/D, 2.49K pullup to 5V
See "Coolant Temperature" Setup
Wizard f or selection.
C1-67
Analog_In_Temp_2
Intake Air
Temperature
72
62
12 bit A/D, 2.49K pullup to 5V
See "Air Temperature" Setup Wizard
f or selection.
C1-68
Harness_Analog_In
_Temp_3
Oil Temperature
Sensor
12 bit A/D, 2.49K pullup to 5V
See 1D table OilTempCal table f or
calibration data and OilTemp [C] f or
channel data.
C1-69
Stepper_2A
Stepper 2A
5
15
Automotiv e, Programmable
Stepper Driv er, up to 28V and
±1.4A
Be sure that each internal coil of the
stepper motor is properly paired with
the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors
only .
