Infinity
Pin
Hardware
Reference
7100-XXXX-62
7101-XXXX-63
Function
Dest.
Pin
Evo
VIII
Dest.
Pin
Evo IX
Hardware Specification
Notes
C1-20
AGND_1
Sensor Ground
40
Dedicated analog ground
Analog 0–5V sensor ground
C1-21
Crankshaf t Position
Sensor Hall
Crankshaf t
Position Sensor
Hall
89
43
10K pullup to 12V. Will work
with ground or f loating switches.
See Setup Wizard page Cam/Crank
f or options.
C1-22
Camshaf t Position
Sensor 1 Hall
Camshaf t
Position Sensor
1 Hall
88
50
10K pullup to 12V. Will work
with ground or f loating switches.
See Setup Wizard page Cam/Crank
f or options.
C1-23
Digital_In_2
Camshaf t
Position Sensor
2 Hall
90
53
10K pullup to 12V. Will work
with ground or f loating switches.
See Setup Wizard page Cam/Crank
f or options.
C1-24
Digital_In_3
Turbo Speed Hz
10K pullup to 12V. Will work
with ground or f loating switches.
See Setup Wizard page Input
Function Assignment f or calibration
constant. TurboSpeed [RPM] = Turbo
[Hz] * Turbo Speed Calibration.
C1-25
Digital_In_4
Vehicle Speed
Sensor
86
80
10K pullup to 12V. Will work
with ground or f loating switches.
See Setup Wizard page Input
Function Assignment f or calibration
constant.
C1-26
Digital_In_5
Flex Fuel
10K pullup to 12V. Will work
with ground or f loating switches.
See channel FlexDigitalIn [Hz] f or raw
f requency input data.
C1-27
Knock Sensor 1
Knock Sensor 1
78
91
Dedicated knock signal
processor
See Setup Wizard page Knock Setup
f or options.
C1-28
Knock Sensor 2
Knock Sensor 2
Dedicated knock signal
processor
See Setup Wizard page Knock Setup
f or options.
C1-29
+12V_Relay _Contr
ol
+12V Relay
Control
38
57
0.7A max ground sink f or
external relay control
Will activ ate at key on and at key
of f according to the conf iguration
settings.
C1-30
Power Ground
Ground
13
46
Power Ground
Connect directly to battery ground.
C1-31
CANL_Aout
AEMNet CANL
Dedicated High Speed CAN
Transceiv er
Recommend twisted pair (one twist
per 2") with terminating resistor.
Contact AEM f or additional
inf ormation.
C1-32
CANH_Aout
AEMNet CANH
Dedicated High Speed CAN
Transceiv er
Recommend twisted pair (one twist
per 2") with terminating resistor.
Contact AEM f or additional
inf ormation.
C1-33
LowsideSwitch_1
Boost Control
11
41
Lowside switch, 4A max with
internal f ly back diode.
Inductiv e load should NOT
hav e f ull time power.
See Setup Wizard page Boost Control
f or options. Monitor BoostControl [%]
channel f or output state.
C1-34
Lowside Fuel Pump
driv e
Fuel Pump
22
21
Lowside switch, 4A max, NO
internal f ly back diode.
Switched ground. Will prime f or 2
seconds at key on and activ ate if
RPM > 0.
