AEM Infinity Supported Applications - Mitsubishi 2006 Evolution IX Engine User Manual
Page 14

14
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware
Reference
7100-XXXX-62
7101-XXXX-63
Function
Dest.
Pin
Evo
VIII
Dest.
Pin
Evo IX
Hardware Specification
Notes
C1-41
+5V_Out_1
+5V Out
81
42
Regulated, f used +5V supply
f or sensor power
Analog sensor power
C1-42
+5V_Out_1
+5V Out
Regulated, f used +5V supply
f or sensor power
Analog sensor power
C1-43
HighsideSwitch_1
HS1 (switched
12V)
0.7A max, High Side Solid State
Relay
See Setup Wizard page 'HighSide
Assigment Tables' f or conf iguration
options.
See 2D lookup table 'HS1_Table' f or
activ ation settings.
C1-44
HighsideSwitch_0
VTEC
0.7A max, High Side Solid State
Relay
See Setup Wizard page 'HighSide
Assigment Tables' f or conf iguration
options.
See 2D lookup table 'HS0_Table' f or
activ ation settings.
See Setup Wizard page 'VTEC' f or
def ault activ ation criteria.
C1-45
Crankshaf t Position
Sensor VR+
Crankshaf t
Position Sensor
VR+
Dif f erential Variable Reluctance
Zero Cross Detection
See Setup Wizard page Cam/Crank
f or options.
C1-46
Crankshaf t Position
Sensor VR-
Crankshaf t
Position Sensor
VR-
See Setup Wizard page Cam/Crank
f or options.
C1-47
Camshaf t Position
Sensor 1 VR-
Camshaf t
Position Sensor
1 VR-
Dif f erential Variable Reluctance
Zero Cross Detection
See Setup Wizard page Cam/Crank
f or options.
C1-48
Camshaf t Position
Sensor 1 VR+
Camshaf t
Position Sensor
1 VR+
See Setup Wizard page Cam/Crank
f or options.
C1-49
VR+_In_2
Non Driv en
Lef t Wheel
Speed Sensor +
Dif f erential Variable Reluctance
Zero Cross Detection
See Non Driv en Wheel Speed
Calibration in the Setup Wizard Input
Function Assignment page.
C1-50
VR-_In_2
Non Driv en
Lef t Wheel
Speed Sensor -
C1-51
VR-_In_3
Driv en Lef t
Wheel Speed
Sensor -
Dif f erential Variable Reluctance
Zero Cross Detection
See Driv en Wheel Speed Calibration
in the Setup Wizard Input Function
Assignment page.
C1-52
VR+_In_3
Driv en Lef t
Wheel Speed
Sensor +
C1-53
DBW1 Motor -
DBW Motor
Control Close
5.0A max Throttle Control
Hbridge Driv e
+12V to close
C1-54
DBW1 Motor +
DBW Motor
Control Open
5.0A max Throttle Control
Hbridge Driv e
+12V to open
