**Cam / Crank Angle Sensor: AEM trigger disc MUST be used
Discrepancies have been observed in the OEM cam/crank signals between model years
and/or trim levels; to avoid confusion the Series 2 EMS does not support the OEM Nissan
trigger pattern. A replacement trigger disc is now included with every Nissan EMS and
must be installed before attempting to start the engine. The following installation was
performed on a stock 300ZX. Installation in a Skyline or modified 300ZX may require
removal of different components to access the CAS sensor, but the procedure for the CAS
disc change should be identical.
Tools/parts required:
• Replacement trigger disc for Nissan RB/VG/VE cam angle sensor
(AEM P/N 35-8761, supplied with 30-6620 EMS)
• ¼”
ratchet
• 4-6”
extension
• 8mm
socket
• 10 mm socket
• Sharpie
• Pick
• Small needle-nose pliers
• ¼ ” flat screwdriver
• No. 1 Phillips screwdriver
• No. 2 Phillips screwdriver
• Small mallet or dead blow hammer
• Medium-sized
hammer
• Small prybar (or wide flat screwdriver)
• 3 M4x45mm cap screws (available at McMaster-Carr in pack of 25 for $1.47; p/n:
91280A149)
• Medium-sized
pliers
• 3/8” pin punch
• 1/8” pin punch
• Vise or area to place sensor assembly on
• Red
threadlocker
WARNING:
Failure to perform the following procedure correctly could result in permanent damage to
mechanical and electrical sensor components, which could result in engine damage.
Please read all instructions carefully before attempting this procedure, and do not attempt
the install if you feel you may not be able to perform all operations safely without
damaging components. AEM will not be held liable for any damage that occurs as a result
of these instructions.
