88 Model 10054 Rev. 11/03
Operation
3 Foot Truss Boom w/Winch - Outriggers Down
4110380
10054
WITH SKY TRAK APPROVED
TRUSS BOOM WINCH ONLY
ALWAYS
• travel slowly
• rig properly
• use two tethers
SWINGING LOADS can
cause MACHINE TIPOVER
which can result in death
or serious injury.
SAFETY INSTRUCTIONS
Use only with vehicles
equipped with auxiliary
hydraulics.
Always connect couplers.
28
0 ft
4
8
16
20
24
32
36
40
44
-4
48
52
56
31 39
28 4 8 12 16 20 24 0 ft 32 36 40
A
B
C
D
E
F
G
H
-8°
20°
40°
68°
30°
60°
0°
12
10°
50°
ASME B56.6 - 2002 PART lll
OH3620
