Operation
29 Model 10054 Rev. 11/03
Travel Select Lever
The Travel Select Lever (3) has three positions to select direction of travel:
F = FORWARD (4) ......... all the way FORWARD
N = NEUTRAL (5) .......... CENTER position
R = REVERSE (6) ...........all the way REARWARD
To change travel selections, move the lever FORWARD or REARWARD to
the desired selection.
When the Travel Select Lever is shifted to REVERSE, the back-up alarm will
automatically sound.
NOTE: The Travel Select Lever must be in the (N) NEUTRAL position to
permit engine starting and when boom angles are greater than 40°, shifting
into NEUTRAL activates the locked mode of the Stabil-TRAK system.
OS0340
OH3260
3
4
5
6
