General Maintenance
149 Model 10054 Rev. 11/03
B. Rear Axle
1. Working through the level plug hole (1), carefully use a screwdriver
to spread the brake disks apart.
IMPORTANT! DO NOT damage the surfaces of the brake disks when
spreading the brake disks.
2. Using a feeler gauge, check the gap (2) between the brake disks
(3). If the gap is greater than .167" (4,25 mm), replace the brake
disks.
NOTE: If the brake disks are worn beyond .167" (4,25 mm), the brake disk
must be replaced on both sides of the axle at the same time.
3. Repeat step 1 and step 2 for the other side of the axle.
4. Continue with step 6 of “B. Axle Oil Change” on page 145.
2
MT2840
3
