Page 150

148

Model 10054

Rev. 11/03

General Maintenance

5. Pressurize the park brake with the pressurizing unit. Close the

pump needle valve on the pressurizing unit.

6. Working through the level plug hole (1), carefully use a screwdriver

to spread the brake disks apart.

IMPORTANT! DO NOT damage the surfaces of the brake disks when
spreading the brake disks.

7. Using a feeler gauge, check the gap (2) between the brake disks

(3). If the gap is greater than .26" (6,75 mm), replace the brake
disks.

NOTE: If the brake disks are worn beyond .26" (6,75 mm), the brake disk
must be replaced on both sides of the axle at the same time.

8. Repeat step 6 and step 7 for the other side of the axle.

MT2850
