Specifi cation s
189
Model 10054 Rev 3/02
Wit hSta ndard 17.5 -2 5T ires :
Leng th( le ss for ks )...... ............ ............. ............. ......239 inch es( 6071 mm)
Wid th (ou trig gers up).. ............ ............. ............. ......102 inch es( 2591 mm)
Wid th (ou trig gers dow n).... ............. ............. .......15 6.75in ches (3 981mm )
Heig ht...... ............. ............. ............. ............. ............ 101in ches (2 565mm )
Wh ee lbas e..... ............. ............ ............. ............. ...1 19.5in ches (3 035mm )
Groun dC lear an ce ............. ............. ............. ............. ...2 0i nc hes( 508mm )
T rea dC enter ........ ............. ............. ............. ......... 84 .25in ches (2 140mm )
Ma ximum Lift Height ......... ............. ............ 53 feet 2i nches (16, 2me ters )
Max .F orw ard Rea ch... ............ ............. ......3 8f eet 9i nches (11, 8me ters )
Cummins:
Mode l...... ............. ............. ............. ............. .....4B T A 3.9 Afte rc ooled T ur bo
Hors epo wer .......... ............. ............. ............. ............. ...116 hp@ 25 00 rpm
Rating: ........ ............. ............ ............. ............. .1 2V DC Negati ve Grou nd
Number ofBa tteri es : ............ ............. ............. ............. ............. ..O ne
Typeof Ba tteries: .....Ma intena nce Free (1 000Col dCr anki ngAm ps)
Series of Bat terie s: ......... ............. ............. ............. ............. Se ries 31
Vehicl eD im ensio ns
Engine
Electr ical System
Specifications
189 Model 10054 Rev 3/02
With Standard 17.5 - 25 Tires:
Length (less forks) .................................................. 239 inches (6071 mm)
Width (outriggers up) .............................................. 102 inches (2591 mm)
Width (outriggers down)..................................... 156.75 inches (3981 mm)
Height...................................................................... 101 inches (2565 mm)
Wheelbase ........................................................... 119.5 inches (3035 mm)
Ground Clearance....................................................... 20 inches (508 mm)
Tread Center ........................................................ 84.25 inches (2140 mm)
Maximum Lift Height .................................. 53 feet 2 inches (16,2 meters)
Max. Forward Reach.................................. 38 feet 9 inches (11,8 meters)
Cummins:
Model ............................................................... 4BTA3.9 Aftercooled Turbo
Horsepower.................................................................116 hp @ 2500 rpm
Rating: ............................................................ 12V DC Negative Ground
Number of Batteries: .................................................................. One
Type of Batteries: .....Maintenance Free (1000 Cold Cranking Amps)
Series of Batteries: ............................................................. Series 31
Vehicle Dimensions
Engine
Electrical System
