Ge nera lM ain ten anc e
129
Model 10054 Rev 3/02
C.Replace In-lineFuel Strainer
1.Un loc ka ndo penthe righ tr eare ngine acces sdo or.
2.T he in -lin efu elstr aine ri slo cated down line fro mth een gines lift
pump (F igur e86) .L oosen thetwo hos ec lamps that sec ure the
str ainer in plac e.
3.Re move theo ldin -lin efue ls trai nera nd dis pose of pro perly .
4.In stall the newin -lin ef uels trai nerw ith arrow pointi ngtowa rd the lift
pum p.
5.A ss embl eth eho se sto the in- line fuels trai neran dt igh ten thehos e
clam ps .
6.Re move airf rom the fuel sy ste m( see “B lee ding Fu elSy stem” on
page 130).
7.Cl ose and loc kthe righ tr eare ngine ac ces sdoo r.
Figure 86
500
OT 1150
OH22 00
In-line Fuel
Strainer
Lift Pu mp
General Maintenance
129 Model 10054 Rev 3/02
C. Replace In-line Fuel Strainer
1. Unlock and open the right rear engine access door.
2. The in-line fuel strainer is located down line from the engines lift
pump (Figure 86). Loosen the two hose clamps that secure the
strainer in place.
3. Remove the old in-line fuel strainer and dispose of properly.
4. Install the new in-line fuel strainer with arrow pointing toward the lift
pump.
5. Assemble the hoses to the in-line fuel strainer and tighten the hose
clamps.
6. Remove air from the fuel system (see “Bleeding Fuel System” on
page 130).
7. Close and lock the right rear engine access door.
Figure 86
500
OT1150
OH2200
In-line Fuel
Strainer
Lift Pump
