3.44
Item No. Part Number Qty. Description
FIRST AND SECOND SHAFT GROUP
(4 Speed)
1 8035036 1 Screw, Locating Sleeve
2 8035050 1 Sleeve, Oil Distributor
3 8035033 2 Ring, Piston
4 8035038 1 Bearing And Seal Assembly
5 8035018 8 Washer, Thrust - Clutch Gear
6 8035019 4 Bearing, Clutch Gear Thrust Washer
7 8034925 1 First Clutch Gear And Bearing Assembly (Includes Item 8)
8 8034918 2 Bearing
9 8035020 2 Snap Ring, End Plate
10 8035021 2 Plate, End
11 8035022 15 Inner Disc - Clutch (10 Required for First and 5 Required for Second)
12 8035023 15 Outer Disc - Clutch (10 Required for First and 5 Required for Second)
13 8035024 2 Snap Ring, Retainer
14 8035025 2 Retainer, Snap Ring
15 8035051 1 First Clutch Disc Spring Assembly (Consists Of 7 Spring Washers)
16 8035027 2 Wear Plate, Clutch Piston
17 8035052 2 Clutch Piston And Seal Assembly (Includes Items 18 and 19)
18 8035029 1 Seal, Clutch Piston - Outer
19 8035030 1 Seal, Clutch Piston - Inner
20 8035053 1 First And Second Shaft, Drum And Plug Assembly
21 8035026 1 Second Clutch Disc Spring Assembly (Consists Of 5 Spring Washers)
22 8034926 1 Second Clutch Gear And Bearing Assembly (Includes Item 23)
23 8034927 2 Bearing
24 8035039 2 Snap Ring, Second Clutch Gear Hub
25 8034928 1 Gear, Third Driven
26 8035054 1 Bearing, Rear
KITS
27 8035089 1 Transmission Gasket And Sealing Kit (Services Entire Transmission)
3606 Origin 7/98
