2.12
Item No. Part Number Qty. Description
THROTTLE PEDAL CONTROL
(Cummins)
1 8162003 1 Pedal, Throttle (Includes Item 2)
2 8033178 1 Bellows, Throttle Pedal
3 8303615 3 HHCS, 1/4-20 x 1-1/4"
4 8307002 3 Washer, Lock 1/4"
5 8307109 4 Washer, Flat SAE 1/4"
6 8305402 2 Nut, Hex Jam 1/4-28 NF
7 8700116 1 Spring, Extension
8 8160073 1 Cable, Throttle
9 8303837 2 Screw, Slotted Pan Hd. #10-24 x 3/4"
10 8160610 1 Clamp, Cable
11 8303799 2 HHCS, M6 x 14mm
12 8307024 2 Washer, Lock M6
13 8340034 1 Rod End 1/4-28 Thd.
14 7127091 1 Extension, Throttle Lever
15 8305650 1 Nut, Hex Lock Elastic 1/4-28 NF
16 8303790 2 HHCS, M12x1.75 x 30mm PC 8,8
17 8307025 2 Washer, Lock M12
18 7127102 1 Bracket, Throttle Cable
19 8305002 2 Nut, Hex #10-24
20 8307003 2 Washer, Lock #10
3606 Origin 7/98
