Page 129
5.2
Item No.
Part Number
Qty.
POWER STEERING CIRCUIT
1
8721029
1
Steering Unit
2
8770102
1
Elbow, 90°, SAE 6-4 - str. thd. ORB x o-ring face seal
3
8770117
3
Connector, Long, SAE 8 - str. thd. ORB x o-ring face seal
4
8770131
1
Check Valve 8-8
5
8770125
1
Tee, Swivel Run, SAE 6 - o-ring face seal
6
8770068
1
Elbow, 90°, SAE 6 - str. thd. ORB x o-ring face seal
7
8902175
1
Valve, Shuttle
8
8770104
1
Elbow, 90°, SAE 6 - str. thd. ORB x o-ring face seal swivel
9
8430032
2
Plug, Dust
10
8430082
1
Nipple, Diagnostic
11
8770126
1
Tee, Branch, SAE 8 - str. thd. ORB x o-ring face seal
12
8770116
4
Connector, SAE 8 - str. thd. ORB x o-ring face seal
13
8430043
1
Nipple, Diagnostic 9/16-18
14
8303757
2
HHCS, 5/16-18 x 2-1/2"
15
8307004
9
Washer, Lock 5/16"
16
8305006
2
Nut, Hex 5/16-18
17
7129572
1
Bracket, Auxiliary Valve Mounting
18
8902170
1
Valve, Steer Select
19
8902111
1
Manifold, Steer Select
20
7129582
1
Bracket, Bulkhead Fittings
21
2715462
1
Hose, 1/2" I.D. x 28.3" Long
22
2715412
1
Hose, 1/2" I.D. x 84" Long
23
2715282
1
Hose, 1/2" I.D. x 14" Long
24
2715252
1
Hose, 1/2" I.D. x 98" Long
25
2715242
1
Hose, 1/2" I.D. x 87" Long
26
2715232
1
Hose, 3/8" I.D. x 13" Long
27
2715152
1
Hose, 1/2" I.D. x 76-1/2" Long
28
2715162
1
Hose, 1/2" I.D. x 78" Long
29
2715142
1
Hose, 1/2" I.D. x 42" Long
30
2715122
1
Hose, 1/2" I.D. x 112" Long
31
2715112
1
Hose, 1/2" I.D. x 30" Long
32
8770113
4
Nut, SAE 8
33
8770114
4
Elbow, 90°, SAE 8 - str. thd. ORB x o-ring face seal
34
8770115
2
Elbow, 90° Swivel, SAE 8 - o-ring face seal
35
8770119
4
Cap, Bleed Adapter, 8 - o-ring face seal
36
8770120
4
Elbow, 90°, M18-8 - metric str. thd. ORB x o-ring face seal
37
8770125
4
Tee, Swivel Run, SAE 8 - o-ring face seal
38
8770128
1
Elbow, 90°, Bulkhead, SAE 8 - o-ring face seal
39
8770129
1
Nut, Bulkhead, SAE 8 - o-ring face seal
40
8310326
2
SHCS, 5/16-18 x 1-1/8"
41
8310327
4
SHCS, #10-24 x 1-1/8"
42
8310165
2
HHCS, M14-2,0 x 20mm
43
8310089
2
Washer, Lock M14
44
7125932
1
Base, Clamp
45
8750014
1
Twin Clamp Set - .62 Hose
46
8750016
9
Twin Clamp Set - .78 Hose
47
8769123
3
Cover Weld - Twin
48
8769128
4
Cover Weld - Twin
49
8750012
5
Stacking Bolt 1-1/8" Long
50
8750015
1
Twin Clamp Set - .68 Hose
51
8750017
5
Locking Plate
52
8310009
4
HHCS, 5/16-18 x 2"
53
8303715
3
HHCS, 5/16-18 x 1-1/2" Gr. 8
54
2715172
1
Hose, 1/2" I.D. x 74" Long
55
8584003
4
Tie Wrap
3606
Origin
7/98
